Technical Parameter
| Experiment method | Standard | Major |
| Diameter of hammer bottom(mm) | 51 | 51 |
| Hammer weight(kg) | 2.5 | 4.5 |
| Height of drop weight (mm) | 305 | 457 |
| Inner diameter of test tube (mm) | 101.6 | 152.4 |
| Height of test tube (mm) | 116 | 116 |
| Test cylinder volume (ml) | 947.4 | 2103.9 |
| Protective tube height (mm) | 50 | 50 |
| Compaction power (KJ/ cm3) | 592.2 | 2684.9 |
